Special cable for robot

Scope of application

The special torsion and bending resistant high flexible cable for robots is designed for motion distortion and instantaneous acceleration when robots work, especially when robots with more than four axes work. The cable is completely oil-resistant and has strong UV resistance. It can be widely used indoors and outdoors. It not only has the high load of torsion movement with its hands, but also is especially suitable for the application of mobile phones, robots or Lanwei sports, It can also be used in situations where anti torsion and high flexibility are required, such as logistics transmission equipment and spindle drive, various drag chain systems and wind turbine nacelle.

product mix

Conductor: multiple fine bare copper stranded conductors with high bending strength (conforming to class 6 in en60228)

Insulation material: special TPE insulation material or bus cable material with high mechanical performance

Identification of wire core: if the cross-section is 0.5mm2 or less, according to din47100; if the cross-section is more than 0.5mm2, the black wire core shall be marked with white numbers according to DIN VDE 0293

Sequence number:

3 core and above, one yellow / Green grounding wire

Cabling: special cabling process and sliding isolation film

Shielding: the shielded cable is shielded by copper wire, and the density is not less than 85%

Outer sheath: low viscosity, no tin plating halogen, PUR based mixture

Color of outer sheath: according to the requirements of relevant products and PAL regulations.

technical parameter

Temperature range: - 25 ℃ - + 80 ℃; Static: - 40 ℃ - + 80 ℃

Minimum bending times: 5 million times

Minimum bending radius: deflection 5 * D; Static 4 * D
