F-Plastic insulated power cable

This product is manufactured according to enterprise standards:

This product is suitable for fixed laying in transmission and distribution lines in high temperature environment with AC 50Hz, rated voltage of 0.6/1kv and below

Executive standard:

Q/321084CDJD05

Technical characteristics:

1. The continuous working temperature of PVDF insulated and sheathed power cable is 150 ℃, and the tensile strength is up to 400kg / cm2. The well has high wear resistance.

2. The continuous working maximum temperature of the power cable with the insulation and sheath of perfluoroethylene propylene is 200 ℃ and it is still flexible at - 60 ℃. The dielectric coefficient is only 2.0, the volume resistance is as high as 10 Ω· cm, and the dielectric breakdown strength is 50ov / mil

3. The continuous working maximum temperature of PTFE insulated and sheathed power cable is 260 ℃, and its electrical performance is equivalent to that of PTFE insulated and sheathed power cable.

4. Fluoroplastic insulated and sheathed power cables have excellent chemical corrosion resistance, weather resistance, flame retardant and waterproof performance.

Delivery length:

1. The single length of the delivered cable shall not be less than 100m, and the quantity of the short section cable with the allowable length not less than 20m shall not exceed 10% of the total length of the delivery

2. According to the agreement of both parties, delivery in any length is allowed.
